Visualisation of pipe flow Deluxe

To visualise laminar and turbulent flow, the Osborne Reynolds experiment is used. The transition from laminar to turbulent flow can be observed above a limiting velocity.

• visualisation of laminar and turbulent flow in the Osborne Reynolds experiment
• visualisation of secondary flow in a pipe elbow
• water as flowing medium and ink as contrast medium
• streamlined inlet and honeycomb rectifier to settle the flow
• horizontal, straight pipe and 90° pipe elbow made of transparent material
• flow rate and temperature in the pipe section can be adjusted via the base module
• automatic identification of accessories via RFID technology
• experiment execution and display of measured values via touch screen (HMI)
• network capability: access to ongoing experiments and their results from up to 10 external workstations simultaneously via the local network
• water supply and heating via the base module
