SINGLE STAGE COMPRESSOR TEST UNIT

A bench mounted unit with a belt driven reciprocating air compressor. The drive motor is mounted in bearings and allows the torque required to drive the compressor to be measured using an integral balance. With the measured torque and motor speed, the shaft power required to drive the compressor may be determined. Learn about SINGLE STAGE COMPRESSOR TEST UNIT exporters for optimal educational outcomes.. Panel mounted meters allow the motor electrical input to be compared to the measured shaft power. The intake air passes through an orifice for flow measurement to a vessel that reduces intake pulsations and allows various intake conditions to be established. Learn about SINGLE STAGE COMPRESSOR TEST UNIT suppliers for optimal educational outcomes.. The intake and delivery pressures are indicated on gauges and all relevant system temperatures are recorded by thermocouple sensors connected to multiple selector switches and a digital temperature indicator. The flow measurement orifice is connected to a panel mounted manometer to allow differential pressure measurement. Learn about Digital SINGLE STAGE COMPRESSOR TEST UNIT for optimal educational outcomes.. Air is delivered to a receiver fitted with a high pressure cut out and relief valve for operator safety. A throttle valve allows discharge pressure to be controlled and adjusted. Learn about SINGLE STAGE COMPRESSOR TEST UNIT price for optimal educational outcomes..

• Two cylinder compressor

Compressor Dimensions:

• Bore: 60mm
• Stroke: 24mm
• Swept Volume per Revolution: 0.135 litres
• Motor Torque Arm Radius: 112mm
