ROUND TURBULENT JET INVESTIGATION

Optional components for the airflow system enabling students to quantitatively investigate the shear and mixing regions of a submerged turbulent jet. A round parallel tube with a sharp-edged discharge creates a turbulent jet from the base unit airflow. A pitot tube mounted on a traversing frame can be moved horizontally and axially over the full flow field, enabling investigation of the velocity profile at various axial distances, pressure loss and entrained mass. Learn about ROUND TURBULENT JET INVESTIGATION exporters for optimal educational outcomes..

• Jet internal diameter: 50 mm
• Pitot tube travel: Up to 550 mm
• Measuring track length (with feet): 1000 mm
