Rotating Body Dynamics and Balancing Test Benches

These benches allow the experimental study of rotating assembly balancing, visualization of vibration phenomena, and validation of observations using associated simulation software. The benches enable: static and dynamic balancing of the rotating assembly without added mass; study of the assembly loaded by one or more masses; dynamic balancing by mass addition on the same or other plates; quantitative study of various vibration types (symmetrical, asymmetrical, damped); quantitative study of various imbalance types (force, couple, general); re-balancing of the rotating system; realization of static and dynamic balancing of unbalanced assemblies with arbitrary-shaped plates and measurement of bearing forces. A simulation software tool illustrates rotating assembly behaviour and determines how it can be re-balanced using point masses. Learn about Rotating Body Dynamics and Balancing Test Benches price for optimal educational outcomes..

Technical Description:

EX180: The bench consists of a shaft guided in rotation by two bearings and fitted with four plates. The assembly is elastically connected to the support via two pairs of steel blades, two of which — supporting the rotating assembly — are equipped with strain gauges for bearing displacement and force measurement.
