Physics Mechanics Kinematics and Dynamic Science Kits for Lab Use in Schools & Colleges ATICO Export

Photogates and digital timer:

• The attractive centrepiece of the MECHANICS 3 and MECHANICS 3 plus experiment sets is formed by the two photogates, which allow experiments in kinematics, dynamics, energy and mechanical oscillations to be carried out especially easily and accurately

• They save enormous amounts of time

• The timer can be used for recording and simultaneously displaying up to three different measurements on a single movement, accurate to the millisecond

• The display remains in place long enough for the readings to be entered into tables

• A reset button then enables the next measurement

• Otherwise, the timer automatically switches to stand-by mode after 60 seconds

• Two AA batteries mean that the timer does not need to be plugged in

• The photogates can either be free-standing or set up in highly variable ways with the help of the supplied holder

Acceleration due to gravity and universal track:

• The light barriers make determining acceleration due to gravity particularly easy and understandable

• A falling steel ball and an identically sized wooden ball both lead to the same results, clearly demonstrating that the acceleration due to gravity does not depend on the mass of the falling body

• The track is used here both as a track and as a stand

• It is not included in the set

Included items:

• Storage case
• Inlay with cut-outs for apparatus, A3
• 2 Photogates
• Digital timer
• 2 Track supports, A3
• Cord, 100 cm, in box
• Balls in box
• Flag
• Coil spring, 3 N/m
• Coil spring, 10 N/m
• Pulley with rod
• Rod with hook, 7 cm
• Wooden pendulum bob
• Steel pendulum bob
• Drop plate
• Pulley holder
• 2 Riders for photogate
• 2 Holders for photogate
• Spring bumper, A2

Additionally required:

• Experiment set MECHANICS 2
• Universal track

Experiments:

• A3-1: Personal reaction times
• A3-2: Frames of reference
• A3-3: Uniform motion
• A3-4: Instantaneous velocity
• A3-5: Uniformly accelerated motion
• A3-6: Free fall
• A3-7: Force and acceleration
• A3-8: Mass and acceleration
• A3-9: Coil spring pendulums 1
• A3-10: Coil spring pendulums 2
• A3-11: String pendulums
• A3-12: The law of conservation of energy in mechanics
• A3-13: Kinetic energy
• A3-14: Non harmonic (irregular) oscillations
