PENDULUM MODULE

An experimental module for use with a vibrations frame, providing compound pendulum and bifilar/trifilar suspension experiments as part of a universal vibration apparatus.

• Compound Pendulum bar: 928 (L) × 25 (W) mm; 7 suspension holes
• Pendulum bob (slotted): Ø60 × 25 mm (t)
• Pendulum bob: Ø28 × 31 mm (L)
• Bifilar/Trifilar rectangular bar: 400 (L) × 32 (W) × 32 (H) mm; approx. 3.1 kg
• Solid cylinder: Ø100 × 70 mm (L); approx. 3.0 kg
• Ring: Ø152 O.D × Ø75 I.D × 25 mm (t); approx. 2.7 kg
