Mini Photo-Bioreactor for Algae Culture

Algae culture is rapidly growing for green chemistry production pathways: biofuels, biofertilisers, etc. Learning Objectives: Determination of oxygen consumption. Reaction monitoring. Learn about Mini Photo-Bioreactor for Algae Culture price for optimal educational outcomes.. Study of algae production parameters: photoperiod, substrate feed, agitation speed, dissolved oxygen level.

15-litre cylindro-conical borosilicate glass reactor with PVC lid and bottom drain valve. Agitator with electronic speed display and regulation; interchangeable impeller — supplied as a 6-blade Rushton turbine.

15-litre cylindro-conical borosilicate glass reactor with PVC lid and bottom drain valve. Agitator with electronic speed display and regulation; interchangeable impeller system. Supplied impeller: 6-blade Rushton turbine. PTFE membrane / 316L stainless steel body metering pump for substrate feed, flow rate 10 L/h. 10 L polyethylene feed tank mounted on a 15 kg / 0.1 g precision balance. The control system calculates flow rate from mass variation and reagent density. Control cabinet housing pump, compressor, and agitator on/off controls, oxygen sensor transmitter, and pH/Redox transmitter. PVC connections; assembly mounted on a welded stainless steel frame suitable for bench or self-supporting installation on castors. pH/Redox measurement and transmitter. Dissolved oxygen measurement with threshold regulation of aeration controlled by dissolved oxygen measurement. Aeration assembly with stainless steel air diffuser, air flow meter, and flow control valve. Pressure-reducing filter included if compressed air is site-supplied. Temperature regulation system with 1000 W electric immersion heater. Photoperiod control: LED lamp at wavelength suitable for algae culture, with timer.
