Electrics 2 Electrostatics / Magnetostatics / Induction Physics Mechanics Science Kits for Lab Use in Schools & Colleges ATICO Export

Electrostatics in any humidity:

• This experiment set covers electrostatics, magnetostatics and electromagnetic induction
• Complements basic circuit studies from ELECTRICITY 1
• Carefully selected materials allow electrostatics experiments even in high humidity conditions

Amazingly distinct magnetic field lines:

• Specially grained iron filings produce very clear magnetic field patterns
• A perspex platform enhances visibility and structure of field lines
• Enables observation of the three-dimensional nature of magnetic fields

Right to the nub of electromagnetic induction:

• Using the 100 mV range of the AMM 300 analog multimeter allows precise measurements

• Zero-point calibration enables clear observation of induction effects

• Experiments on AC generators become highly demonstrative

• Transformer laws can also be explored easily and effectively

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for apparatus, E2
• 1 × Glowlamp on base
• 1 × Battery holder with 3 AA batteries
• 1 × Multi-purpose base
• 1 × Base with sockets
• 1 × Shaker with iron filings
• 2 × Iron keepers
• 2 × AlNiCo cylindrical magnets
• 7 × Iron washers in box
• 1 × Field line platform
• 1 × Iron bar E1
• 1 × Pivot bearing
• 1 × Needle stand
• 1 × Electroscope
• 1 × U-shaped core with yoke
• 1 × Coil with 200/400 windings
• 1 × Coil with 300/600 windings
• 1 × Perspex rod
• 2 × PVC rods
• 1 × Woolen cloth
• 1 × Silk cloth
• 1 × Closed aluminium ring
• 1 × Open aluminium ring
• 4 × Experiment leads, 25 cm, red
• 2 × Experiment leads, 25 cm, blue

Experiments:

• Magnetic poles
• Action and reaction as applied to magnetism
• Magnetic effects
• Magnetic field lines
• A magnet that can be turned on and off**
• Soft iron instruments**
• Electrostatic force
• Electroscopes
• Sign of electric charge
• Electromagnetic induction*
• Lenz’s law
• Self-induction
• Transformer laws**
• AC generators*
• DC motors
