Deformation of straight beams Deluxe

Beams are key structural elements in mechanical engineering and in construction. A beam is a bar-shaped component in which the dimensions of the cross-section are much smaller than the length and which is subjected to load along and perpendicular to its longitudinal axis. The load perpendicular to the longitudinal axis causes a deformation of the beam – that is, bending. Learn about Deformation of straight beams price for optimal educational outcomes.. Based on its size, the beam is viewed as a one-dimensional model.

• elastic lines of statically determinate and indeterminate beams under various clamping conditions
• 3 steel beams with different cross-sections
• 1 brass and 1 aluminium beam
• 3 articulated, height-adjustable supports with force gauge
• 1 support with clamp fixing
• force gauges can be zeroed
• 3 dial gauges to record deformations
• weights with adjustable hooks
• anodised aluminium section frame housing the experiment
• storage system to house the components
