Bernoulli's Theorem Demonstration

Illustrates those circumstances to which Bernoulli's Theorem may be applied. Also, separately, why in other circumstances the theorem gives an inadequate description of the fluid behaviour.

Illustrates those circumstances to which Bernoulli's Theorem may be applied. Also, separately, why in other circumstances the theorem gives an inadequate description of the fluid behavior.

• Manometer range: 0-400mm
• Number of manometer tubes: 11
• Throat diameter: 14mm
• Upstream diameter: 26.0mm
• Upstream taper: 21??
• Downstream taper: 9??

• The classical venturi profile has been enhanced to industry standard, leading to better accuracy and efficiency in demonstrating Bernoulli's theorem
• More pressure tappings have been added, resulting in increased pressure drop resolution
• The manometer height has been increased, allowing the unit to handle greater flowrates, potentially up to 20 L/min
• Provides more detailed analysis of pressure variations within the system
• Offers a more comprehensive understanding of fluid dynamics
