Activated sludge process Deluxe

The activated sludge process is the most important biological process in water treatment. CE 705 enables this process to be demonstrated.

• aeration tank divided into two areas
• secondary clarifier with sludge scraper
• nitrification and pre-denitrification
• separate supply unit with 2 stirring machines
• control and measurement of temperature, oxygen concentration and flow rate
• measurement of pH value in the aeration tank
• ectromagnetic flow rate sensors
• device control with PLC via touch screen
• integrated router for operation and control via an end device and for screen mirroring: mirroring of the user interface on up to 5 end devices
• data acquisition via PLC on internal memory, access to stored measured values via WLAN/LAN with integrated router/LAN connection to customer’s own network or direct LAN connection without customer network
